LM4250 Programmable Op-Amp – Datasheet

5,607 views

LM4250 is a programmable operational amplifier IC. LM4250 is a highly versatile monolithic operational amplifier. A single external programming resistor determines the quiescent power dissipation, input offset and bias currents, slew rate, gain-bandwidth product, and input noise characteristics of the amplifier. The IC is directly compatible with most CMOS, NMOS, and PMOS devices. LM4250 offers many different features such as short circuit protection, ESD barring, and low thermal dissipation. The IC has a wide variety of working voltages and operating conditions.

Programmable Operational Amplifier

A programmable operational amplifier is an industry standard, frequency compensated operational amplifier, whose gain can be controlled by external digital or analog signals. A programmable operational amplifier has two special features when compared with other monolithic operational amplifiers. One is the ability to externally set the bias current levels of the amplifiers, and the other is the use of PNP transistors as a differential input pair.

LM4250 Pinout

LM4250 Pin Configuration

Pin NoPin NameDescription
1OFFSET NULL 1Offset Null Pin 1
2INV-INPUTInverting Input Pin
3NON-INV-INPUTNon Inverting Input Pin
4V-Negative Power Supply
5OFFSET NULL 2Offset Null Pin 2
6OUTPUTOutput Pin
7V+Positive Power Supply
8QUS-CURRENT Quiescent Current Set Pin/Quiescent State

LM4250 Features

  • ±1V to ±18V power supply operation
  • 3 nA input offset current
  • Standby power consumption as low as 500 nW
  • No frequency compensation required
  • Programmable electrical characteristics
  • Offset voltage nulling capability
  • Can be powered by two flashlight batteries
  • Short circuit protection

Application

  • Voltage follower
  • Selective inversion circuit
  • Active rectifier
  • LED Driver
  • Multivibrators
  • Oscillators
  • Transducer Amplifiers
  • Integrator
  • Current-to-voltage converter

LM4250 Datasheet

You can download this datasheet for LM4250 Programmable Op-Amp from the link given below:
