2SK30 N-Channel JFET – Datasheet

7,888 views

2SK30 is N-Channel MOS Field Effect Transistor designed for high current switching applications

2SK30 Pinout

2SK30 Pin Configuration

Pin NoPin Name
1Source
2Gate
3Drain

2SK30 Key Features

  • Super Low On-State Resistance
  • RDS(on)1 = 17 mΩ MAX. (VGS = 10 V, ID = 28 A)
  • RDS(on)2 = 27 mΩ MAX. (VGS = 4.0 V, ID = 28 A)
  • Low Ciss : Ciss = 2100 pF (TYP.)
  • Built-in Gate Protection Diode

Application

  • High current switching applications

You can download this datasheet for 2SK30 N-Channel JFET from the link given below:
