W10M 1000V 1A Full Wave Bridge Rectifier has a High reverse voltage of up to 1000V, Surge overload rating is 50 amperes peak. It is used for printed circuit board assembly, the weight is 1.20 grams.
W10M Pinout
W10M Pin Configuration
| Pin | Description |
|---|---|
| ~ | AC Input |
| ~ | AC Input |
| + | DC Positive Voltage |
| – | DC Negative Voltage |
W10M Features
- Full Wave Bridge Rectifiers
- Wide Range of Voltages and Currents
- Large Quantity Discounts Available
W10M Specification
| Type | Vrrm (V) | Vrms (V) | Vdc (V) | Io (A) | Ir (mA) | Vf (V) |
|---|---|---|---|---|---|---|
| W10M | 1000 | 700 | 1000 | 1.5 | 0.01 | 1.0 |
You can download this datasheet for W10M 1000V 1A Full Wave Bridge Rectifier from the link given below:
