The ULN2004 is a high voltage, high current Darlington array each containing seven open collectors Darlington pairs with common emitters. Each channel is rated at 500mA and can withstand peak currents of 600mA. Suppression diodes are included for inductive load driving and the inputs are pinned opposite the outputs to simplify board layout. The ULN2004 is supplied in 16 pin plastic DIP packages with a copper lead frame to reduce thermal resistance. It is available also in a small outline package (SO-16).
ULN2004 Pinout
ULN2004 Pin Configuration
| Pin No | Pin Name | Description |
|---|---|---|
| 1 | 1B | Input Pin 1B |
| 2 | 2B | Input Pin 2B |
| 3 | 3B | Input Pin 3B |
| 4 | 4B | Input Pin 4B |
| 5 | 5B | Input Pin 5B |
| 6 | 6B | Input Pin 6B |
| 7 | 7B | Input Pin 7B |
| 8 | E | Enable Pin |
| 9 | COM | Common Pin |
| 10 | 7C | Output Pin 7C |
| 11 | 6C | Output Pin 6C |
| 12 | 5C | Output Pin 5C |
| 13 | 4C | Output Pin 4C |
| 14 | 3C | Output Pin 3C |
| 15 | 2C | Output Pin 2C |
| 16 | 1C | Output Pin 1C |
ULN2004 Features
- TTL, DTL, PMOS, or CMOS-Compatible Inputs
- Output Current to 500 mA
- Output Voltage to 95V
- Transient-Protected Outputs
- Dual In-Line Plastic Package or Small-Outline IC Package
Application
- Solenoids
- Relays DC Motors
- LED Displays filament Lamps
- Thermal Print heads
- High Power Buffers
You can download this datasheet for ULN2004 Hi-Voltage/Current Darlington Transistor – Datasheet from the link given below:
