Introduction
Switched-mode power supply (SMPS) is an abbreviation for switch-mode power supply. SMPS is a high-efficiency power supply that is commonly used in electronic equipment such as computers, battery chargers, and other electrical equipment that requires a consistent and efficient power supply. It’s being used to convert power (voltage) utilizing switching devices that are switched on and off at high frequencies alternately. So in this tutorial, we are going to discuss the “tiny SMPS power module”.
Hardware Overview
These are isolated switching step-down power supply modules with a PCB mount and a plastic enclosure. The input power supply for these modules is 100 to 240 Vac with a frequency of 50-60 Hz, and the output is Constant DC (5V or 12V depending on the module).
Because these modules do not require stepping-down transformers, rectifiers, regulators, or filters, the cost of designing a power supply is significantly lowered. It offers high output efficiency, high dependability, minimal temperature increase, and excellent security isolation, among other benefits.
These modules provide accurate bias to the microcontroller and embedded electronics projects.
Features of tiny SMPS power module
- Ultra-thin, ultra-small
- All voltage input (AC: 90 ~ 264V)
- Low ripple and low noise
- Output overload and short circuit protection
- High efficiency, high power density
- The product is designed to meet the requirements of EMC and Safety Test
- Low power consumption, environmental protection, no-load loss <0.1W
Specifications
- Rated input voltage: 100-240VAc
- Input voltage range: 90-264VAc
- Maximum input current: ≤0.2A
- Input current surge: ≤10A
- Maximum input voltage: ≤270VAc
- Enter slow start: ≤50 mS
- Input Low Voltage Efficiency : Vin=110VAc，Output full-load≥69%
- Input High Voltage Efficiency : Vin=220VAc，output full-load≥70%
- Long-term reliability: MTBF≥100，000h
- Load-rated output voltage: +3.3±0.1VDc
- Full rated output voltage: +3.3±0.2 VDC
- Short-term maximum output current : ≥1200mA
- The maximum output current for a long time : ≥1000mA
- Voltage Regulation: ±0.2 %
- Load Regulation: ±0.5
Application and Uses
- Servers, power stations, and personal PCs all utilize it.
- We can use it to charge batteries in automobiles.
- Also, to generate electricity in factories.
