The TDA7296 is a monolithic integrated circuit in the Multiwatt15 package, intended for use as an audio class AB amplifier in Hi-Fi field applications (Home Stereo, self-powered loudspeakers, Top class TV). Thanks to the wide voltage range and to the high out current capability it is able to supply the highest power into both 4Ω and 8Ω loads even in presence of poor supply regulation, with high Supply Voltage Rejection. The built-in muting function with turn-on delay simplifies the remote operation avoiding switching on-off noises.
TDA7296 Pinout
TDA7296 Pin Configuration
| Pin No | Pin Name | Description |
|---|---|---|
| 1 | ST-BY GND | Stand By Ground |
| 2 | INV-IN | Inverting Input |
| 3 | NON-INV-INPUT | Non Inverting Input |
| 4 | SVR | Supply Voltage Rejection |
| 5 | NC | No Connection |
| 6 | BOOTSTRAP | Bootstrap |
| 7 | +Vs (SIGNAL) | Positive Supply Voltage (Signal) |
| 8 | -Vs (SIGNAL) | Negative Supply Voltage (Signal) |
| 9 | ST-BY | Stand By |
| 10 | MUTE | Mute Pin |
| 11 | NC | No Connection |
| 12 | NC | No Connection |
| 13 | +Vs (POWER) | Positive Supply Voltage (Power) |
| 14 | OUT | Output |
| 15 | -Vs (POWER) | Negative Supply Voltage (Power) |
TDA7296 Key Features
- Very High Operating Voltage Range (±35V)
- DMOS Power Stage
- High Output Power (UP TO 60W MUSIC POWER)
- Muting and stand-by functions
- No switch on/off noise
- Very low distortion
- Very low noise
- Short-circuit protected (with no input signal applied)
- Thermal shutdown
- Clip detector
Application
- Home Stereo
- Self Powered Loudspeakers
- Top class TV
You can download this datasheet for TDA7296 70V 60W DMOS Audio Amplifier from the link given below:
