T106D1 4A 400V SCR – Datasheet

T106D1 4A 400V SCR semiconductor is a half-wave unidirectional, gate-controlled rectifier (SCR-thyristor) that complements Teccor’s line of power SCRs. This group of packages offers ratings of 0.8 A to 10 A, and 200 V to 600 V with gate sensitivities of 12 µA to 500 µA. For gate currents in the 10 mA to 50 mA ranges, see “SCRs” section of this catalog

T106D1 Pinout

T106D Pin Configuration

Pin No	Pin Name
1	Cathode
2	Anode
3	Gate

T106D1 Key Features

• RoHS Compliant
• Electrically-isolated TO-220 package
• High voltage capability — up to 600 V
• High surge capability — up to 100 A
• Glass-passivated chip

T106D1 Specification

Type	Vdsm (V)	Vrsm (V)	It (A)	Igt (uA)	Vgt (V)
T106D1	400	400	4.0	200	0.8

Application

• It is used for a wide range of switching applications

You can download this datasheet for T106D1 4A 400V SCR – Datasheet from the link given below:
