Simple Tachometer Circuit

4,842 views

Introduction

If you have a car and you are used to driving it, then you must have an idea of what a tachometer is; if not, then know that in cars, there is a device that indicates which gear your vehicle is in. This device is a tachometer device. The operation of a car’s engine is monitored using a tachometer. To put it another way, it is a device or equipment that is used to monitor the rotational speed of a spinning device. To put it another way, this device calculates the RMS factor; i.e. rotations per minute. This device is most frequently used to identify the speed of a rotating shaft operated by an engine. So, In this tutorial, we have decided to make a “Simple Tachometer Circuit”.

To make this tachometer, here we are using easily available parts electronic components such as MOC7811 and two seven-segment display units. With this circuit, we can measure the speed of a spinning shaft or disc in RPS.

ne555-timer-ic

Hardware Components

The following components are required to make Tachometer Circuit

S.noComponentValueQty
1IC NE555 Timer1
2MOC 78111
3IC CD4081, CD4069, CD40331
4LED1
5Push Button1,1
6Switch1
7Potentiometer 4.7K1
8Capacitor 0.1uF1
9Electrolyte Capacitor 100uF1
10Resistor1KΩ, 8.2KΩ, 220KΩ, 220Ω, 470Ω, 390Ω2,1,1,1,1,1,1
113-Pin Connector1
127-Segment Display2

NE555 IC Pinout

555 timer ic pinout

For a detailed description of pinout, dimension features, and specifications download the datasheet of NE555 IC

CD4069 Pinout

CD4069-Pinout

For a detailed description of pinout, dimension features, and specifications download the datasheet of CD4069

CD4033 Pinout

CD4033 IC Pinout

For a detailed description of pinout, dimension features, and specifications download the datasheet of CD4033

Tachometer Circuit

tachometer-circuit-using-555-timer-diagram-schematic

Working Explanation

This Simple Tachometer Circuit includes the IC555, MOC 7811, IC CD4081, IC CD4069, and IC 4033, as well as the LTS 543 seven-segment display unit. The green LED1 displays the sensing length when the timer IC 555 is set as a monostable multivibrator. Thus,  produces a timing pulse when switch S2 is pushed.

The MOC 7811 IC2 has an infrared transmitter and photodiode that create different logic levels depending on whether the IR light beam is blocked or interrupted. CD4033, a Johnson decade counter, is enabled by AND logic gate N1 and this counter operate the seven-segment.

Application and Uses

  • With the help of a tachometer, one can determine the engine’s overall conditions.
  • To determine the operating speed of the motor.
  • In automotive vehicles and cars, etc.
