Security door alarms are simple electronic devices that trigger when an intruder or trespasser tries to gain access to any designated area. They are a necessary part of today’s home security systems. There are a number of electronic configurations available to implement such home security alarms. Here, we will take a look at implementing using a reed switch.
The heart of this circuit is a magnetic reed switch. A reed switch comprises two ferromagnetic blades, separated by only a few microns. When another magnet comes close to these blades, the two blades pull towards one another. Once touching, the blades close the normally open (NO) contacts, allowing electricity to flow. Some reed switches also contain a non-ferromagnetic contact, which forms a normally closed (NC) output. Any approaching magnet will disconnect the contact and pull away from the switching contact.
PCBWay commits to meeting the needs of its customers from different industries in terms of quality, delivery, cost-effectiveness, and any other demanding requests. As one of the most experienced PCB manufacturers in China. They pride themselves to be your best business partners as well as good friends in every aspect of your PCB needs.
Hardware Components
The following components are required to make Door Security Alarm Circuit
| S.no | Component | Value | Qty |
|---|---|---|---|
| 1 | Reed Switch | – | 1 |
| 2 | NPN Transistor | BC547 | 2 |
| 3 | LED | 3.5V/5mm | 1 |
| 4 | Buzzer | 5V | 1 |
| 5) | Resistor | 680 Ohm, 100K | 2 |
| 6 | Capacitor | 220uF/50V | 1 |
| 7 | Soldering Iron | 45W – 65W | 1 |
| 8 | Soldering wire with flux | – | 1 |
| 9 | Security Door Alarm PCB | – | 1 |
| 10 | DC Battery | 9V | 1 |
| 11 | Battery clip | – | 1 |
| 12 | Block Connectors | – | 1 |
BC547 Pinout
For a detailed description of pinout, dimension features, and specifications download the datasheet of BC547
Door Security Alarm Circuit
Working Explanation
This circuit can be attached to any entry point such as doors, gates, etc, or any storage unit such as safes or drawers, where you want no intruders to trespass. As the safe/door with one terminal of reed switch attached to the surface is opened & brought close to the second terminal of the reed switch placed in close proximity. The magnetic connection is made through mutual inductance & sends a control signal to the base of the first BC547 transistor.
The collector output of the first transistor triggers the 5V buzzer & the alarm goes off. In order to turn off the alarm, you simply displace the door back to its original position, moving the two reed switch terminals away from each other. This demagnetizes the two terminals & turns OFF the alarm.
Applications
- Commonly used in high-risk areas such as security stations, police stations & checkpoints.
- An important security feature in sensitive workplaces such as military compounds.
