S6010L 10A 600V SCR semi-conductor is a half-wave, unidirectional, gate-controlled rectifier that complements Teccor’s line of sensitive SCRs. Teccor offers devices with ratings of 1 A to 70 A and 200 V to 1000 V, with gate sensitivities from 10 mA to 50 mA. If gate current in the 12 µA to 500 µA ranges is required, see the “Sensitive SCRs” section of this catalog.
S6010L Pinout
S6010L Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Cathode |
| 2 | Anode |
| 3 | Gate |
S6010L Key Features
- RoHS Compliant
- Electrically-isolated package
- High voltage capability — 200 V to 1000 V
- High surge capability — up to 950 A
- Glass-passivated chip
S6010L Specification
| Type | Vdsm (V) | dV/dT (V/µs) | Vgt (V) | It (A) | Igt (mA) |
|---|---|---|---|---|---|
| S6010L | 600 | 425 | 1.5V | 10.0 | 30 |
Application
- It is used for a wide range of switching applications
You can download this datasheet for S6010L 10A 600V SCR – Datasheet from the link given below:
