S6006L 6A 600V SCR semi-conductor is a half-wave, unidirectional, gate-controlled rectifier that complements Teccor’s line of sensitive SCRs. Teccor offers devices with ratings of 1 A to 70 A and 200 V to 1000 V, with gate sensitivities from 10 mA to 50 mA. If gate currents in the 12 µA to 500 µA ranges are required, see the “Sensitive SCRs” section of this catalog.
S6006L Pinout
S6006L Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Cathode |
| 2 | Anode |
| 3 | Gate |
S6006L Key Features
- RoHS Compliant
- Electrically-isolated package
- High voltage capability — 200 V to 1000 V
- High surge capability — up to 950 A
- Glass-passivated chip
S6006L Specification
| Type | Vdsm (V) | dV/dT (V/µs) | Vgt (V) | It (A) | Igt (mA) |
|---|---|---|---|---|---|
| S6006L | 600 | 425 | 1.5V | 6.0 | 30 |
Application
- It is used for a wide range of switching applications
You can download this datasheet for S6006L 6A 600V SCR – Datasheet from the link given below:
