S4015L 15A 400V SCR semiconductor is half-wave, unidirectional, gate-controlled rectifiers complement Teccor’s line of sensitive SCRs. Teccor offers devices with ratings of 1 A to 70 A and 200 V to 1000 V, with gate sensitivities from 10 mA to 50 mA. If gate currents in the 12 µA to 500 µA ranges are required, see the “Sensitive SCRs” section of this catalog.
S4015L Pinout
S4015L Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Cathode |
| 2 | Anode |
| 3 | Gate |
S4015L Key Features
- RoHS Compliant
- Electrically-isolated package
- High voltage capability 200 V to 1000 V
- High surge capability up to 950 A
- Glass-passivated chip
S4015L Specification
| Type | Vdsm (V) | dV/dT (V/µs) | Vgt (V) | It (A) | Igt (mA) |
|---|---|---|---|---|---|
| S4015L | 400 | 450 | 1.5V | 15.0 | 30 |
Application
- It is used for a wide range of switching applications
You can download this datasheet for S4015L 15A 400V SCR – Datasheet from the link given below:
