RHRG75120 75A 1200V Hyper fast Diode – Datasheet

1,957 views

The RHRG75120 is a hyper fast diode with soft recovery characteristics. It has half the recovery time of ultrafast diodes and is silicon nitride passivated ion-implanted epitaxial planar construction.

RHRG7512O Pinout

RHRG75120 Features

  • With TO-247 packaging
  • High performance fast recovery diode
  • Low loss and soft recovery
  • Low forward voltage drop
  • Minimum Lot-to-Lot variations for robust device performance and reliable operation

RHRG75120 Specification

Diode TypeRectifier Diode
ApplicationHyperfast Soft Recovery
Diode Element MaterialSilicon
Forward Voltage-Max (VF)2.6  V
Non-rep Pk Forward Current-Max500.0  A
Operating Temperature-Min-65.0  Cel
Operating Temperature-Max175.0  Cel
Output Current-Max75.0  A
Rep Pk Reverse Voltage-Max1200.0  V
Reverse Recovery Time-Max0.1  µs

Applications

  • Switching power supply
  • Power switching circuits
  • General purpose

You can download this datasheet for RHRG75120 75A 1200V Hyper fast Diode from the link given below:
