The PN2907A is a silicon Planar Epitaxial PNP transistor in Jedec TO-92 (for PN2907) metal case. It is designed for high speed saturated switching and general-purpose applications
PN2907A Pinout
PN2907A Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Emitter |
| 2 | Base |
| 3 | Collector |
PN2907A Key Features
- Low Collector Saturation voltage
- High Speed Switching
- For Complementary Use with NPN Type HPN2222A Absolute Maximum Ratings
PN2907A Specification
| Name | Description |
|---|---|
| Collector-Emitter Voltage (Vce) | 60 V |
| Collector-Base Voltage (Vcb) | 60 V |
| Emitter-Base Voltage (Veb) | 5 V |
| Collector Current (Ic) | 0.6 A |
| Collector Power Dissipation (Pc) | 0.625 W |
| Transition Frequency | 200 MHz |
Application
- Switching and linear amplification.
You can download this datasheet for PN2907A PNP General Purpose Transistor – Datasheet from the link given below:
