PN200 PNP General Purpose Transistor – Datasheet

1,852 views

PN200 PNP General Purpose Transistor is designed for general-purpose amplifier applications at collector currents to 300 mA

PN200 Pinout

PN200 Pin Configuration

Pin NoPin Name
1Emitter
2Base
3Collector

PN200 Specification

NameDescription
Collector-Emitter Voltage (Vce)35 V
Collector-Base Voltage (Vcb) 60 V
Emitter-Base Voltage (Veb) 5 V
Collector Current (Ic)  0.5 A
Collector Power Dissipation (Pc) 0.625 W
Transition Frequency 150 MHz

Application

  • General-purpose amplifier applications at collector currents to 300 mA

You can download this datasheet for PN200 PNP General Purpose Transistor – Datasheet from the link given below:
