MUR410G 4A 100V Ultra-Fast Recovery Diode – Datasheet

MUR410G 4A & 100V Ultrafast Recovery Diode is a series of switch mode power rectifiers and is designed for use in switching power supplies, inverters and as free wheeling diodes.

MUR410G Pinout

MUR410G Features

• Ultrafast 25 ns, 50 ns and 75 ns Recovery Times
• 175°C Operating Junction Temperature
• Low Forward Voltage
• Low Leakage Current
• High Temperature Glass Passivated Junction
• Reverse Voltage to 600 V
• Shipped in Plastic Bags, 500 per Bag
• Available in Tape and Reel, 1500 per Reel, by Adding a “RL’’ Suffix to the Part Number
• Pb−Free Packages are available

MUR410G Specification

Mfr Package Description	Case 267-03, 2 Pin
Diode Type	Rectifier Diode
Application	Ultra Fast Recovery Power
Forward Voltage-Max (VF)	0.71  V
Non-rep Pk Forward Current-Max	125.0  A
Operating Temperature-Min	-65.0  Cel
Operating Temperature-Max	175.0  Cel
Output Current-Max	4.0  A
Peak Reflow Temperature (Cel)	260
Rep Pk Reverse Voltage-Max	100.0  V
Reverse Recovery Time-Max	0.035  µs
Time Peak Reflow Temperature-Max (s)	40

Application

• switching power supplies
• inverters
• wheeling diodes

You can download this datasheet for MUR410G 4A 100V Ultra-Fast Recovery Diode from the link given below:
