MUR1660CT 8A & 600V Ultrafast Recovery Diode is a series of switch mode power rectifiers and is designed for use in switching power supplies, inverters and as free wheeling diodes.
MUR1660CT Pinout
MUR1660CT Features
- Ultrafast 35 and 60 Nanosecond Recovery Times
- 175°C Operating Junction Temperature
- Popular TO−220 Package
- Epoxy Meets UL 94 V−0 @ 0.125 in
- High Temperature Glass Passivated Junction
- High Voltage Capability to 600 V
- Low Leakage Specified 150°C Case Temperature
- Current Derating Both Case and Ambient Temperatures
- Pb−Free Packages are Available
MUR1660CT Specification
| Mfr Package Description | ROHS Complaint, Plastic Package-3 |
| Diode Type | Rectifier Diode |
| Application | General Purpose |
| Diode Element Material | Silicon |
| Forward Voltage-Max (VF) | 1.5 V |
| Non-rep Pk Forward Current-Max | 100.0 A |
| Operating Temperature-Min | -65.0 Cel |
| Operating Temperature-Max | 175.0 Cel |
| Rep Pk Reverse Voltage-Max | 600.0 V |
| Reverse Current-Max | 10.0 µA |
| Reverse Recovery Time-Max | 0.05 µs |
You can download this datasheet for MUR1660CT 8A 600V Dual Ultra-Fast Recovery Diode from the link given below:
