MPF102N-Channel RF Amplifier is designed for electronic switching applications such as low ON resistance analog switching.
MPF102 Pinout
MPF102 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Drain |
| 2 | Source |
| 3 | Gate |
MPF102 Key Features
- Type Designator: MPF102
- Type of Transistor: JFET
- Type of Control Channel: N -Channel
MPF102 Specification
| Id (A) | Pd (W) | Vds (max) | Vgs (max) |
|---|---|---|---|
| 0.02 | 0.35 | 25 | 7.5 |
MPF102 Equivalent/Alternative
- MPF4393, MPF6659, MPF6660, MPF6661, MPF930, MPF960, MPF990
Application
- Low ON Resistance Analog Switching
You can download this datasheet for MPF102 JFET N-Channel VHF Amplifier from the link given below:
