The MJ15022 NPN Power Base power transistors designed for high power audio, disk head positioners and other linear application
MJ15022 Pinout
MJ15022 Pin Configuration
Pin No | Pin Name |
---|---|
1 | Base |
2 | Emitter |
3 | Collector |
MJ15022 Key Features
- High Safe Operating Area (100% Tested) — 2 A @ 80 V
- High DC Current Gain — hFE = 15 (Min) @ IC = 8 A
- Type Designator: MJ15022
- Material of Transistor: Si
- Polarity: NPN
- Maximum Emitter-Base Voltage |Veb|: 7 V
MJ15022 Specification
Ic (mA) | Pd | Vce (max) | Vcb | hfe | @Ic | Ft |
---|---|---|---|---|---|---|
16 | 250 | 200 | 350 | 15-60 | 8000 | 4 |
MJ15022 Equivalent/Alternate:
- MJ10000, MJ10001, MJ10002, MJ10003, MJ10004, MJ15023/15025
Application
- High Power Audio
- Disk Head Positioner
You can download this datasheet for MJ15022 NPN Power Transistor from the link given below:
