MC4558 Wide Bandwidth Dual Operational Amplifier – Datasheet

6,951 views

MC4558 is a high-performance monolithic dual operational amplifier. The circuit combines all the outstanding features of the MC1458 and, in addition, possesses three times the unity-gain bandwidth of the industry standard. The IC is constructed using gated P-channel MOSFET at the input; so, as to provide a very high input impedance. The IC has a wide range of working voltages and directly interfaces with both passive and active electronic components; making it ideal to be used with any device.

Operational Amplifiers

An operational amplifier or op-amp is simply an electronic linear Integrated Circuit or IC that has multiple terminals. An op-amp is a voltage amplifying device that is meant to be work with external feedback components such as resistors and capacitors. Operational amplifiers are considered to be one of the most vastly used electronic component, with applications ranging from small scale consumer electronic components such as smartphones, tablets, PCs, to large scale industrial instrumentation tools such as poisonous gas sensors and transducers for impurity detection.

There are two main classifications of amplifiers:

  • Inverting Amplifiers
  • Non – inverting amplifiers

MC4558 Pinout

MC4558 Pin Configuration

Pin NoPin NameDescription
1OUTPUT 1Output Of Amplifier 1
2INV-INPUT 1Inverting Input Of Amplifier 1
3NON-INV-INPUT 1Non Inverting Input Of Amplifier 1
4VCC(-)Negative Power Supply
5ON-INV-INPUT 2Non Inverting Input Of Amplifier 2
6INV-INPUT 2Inverting Input Of Amplifier 2
7OUTPUT 2Output Of Amplifier 2
8VCC+Positive Power Supply

MC4558 Features

  • Internally compensated
  • Short-circuit protection
  • Gain and phase match between amplifier
  • Low power consumption
  • Pin-to-pin compatible with MC1458/LM358
  • Gain bandwidth product (at 100kHz): 5.5MHz

Application

  • Voltage regulators
  • Precision circuits
  • Analog-to-digital converters
  • Digital-to-analog converters

MC4558 Datasheet

You can download this datasheet for MC4558 Wide Bandwidth Dual Operational Amplifier from the link given below:
