LM2679 Adjustable 5A Step-Down Voltage Regulator – Datasheet

2,213 views

The LM2679 regulator is a monolithic integrated circuit that provides all of the active functions for a stepdown (buck) switching regulator capable of driving up to 5A loads with excellent line and load regulation characteristics. High efficiency (>90%) is obtained through the use of a low ON-resistance DMOS power switch. The LM2679 consists of a fixed adjustable output version.

Other features include the ability to reduce the input surge current at power-ON by adding a soft-start timing capacitor to gradually turn on the regulator. The LM2679 also has a built-in thermal shutdown and resistor programmable current limit of the power MOSFET switch to protect the device and load circuitry under fault conditions.

LM2679 Pinout

LM2679 Pin Configuration

Pin NoPin NameDescription
1SWITCH OUTSwitch Output Pin
2INPUTInput Pin
3C BOOSTC Boost Pin
4GNDGround Pin
5CURRENT ADJ:Current Adjust Pin
6FEEDBACKFeedback Pin
7SOFTSTARTSoft Start Pin

LM2679 Key Features

  • Simple and easy to design with (using off-the-shelf external components)
  • Resistor programmable peak current limit over a range of 3A to 7A.
  • 120 mΩ DMOS output switch
  • 3.3V, 5V and 12V fixed output and adjustable (1.2V to 37V ) versions
  • ±2%maximum output tolerance over full line and load conditions
  • Wide input voltage range: 8V to 40V
  • 260 KHz fixed frequency internal oscillator
  • Softstart capability

Application

  • Simple to design, high efficiency (>90%) step-down switching regulators
  • Efficient system pre-regulator for linear voltage regulators
  • Battery chargers

You can download this datasheet for LM2679 Adjustable 5A Step-Down Voltage Regulator – Datasheet from the link given below:
