LH0063 Ultra Fast Buffer – Datasheet

2,120 views

The LHO063 is a high-speed, FET input, voltage follower/buffers designed to provide high current drive at frequencies from DC to 300MH. Both devices are similar in their slew rate; up to 6000 volts per microsecond with light loads and 2000 volts per microsecond with a 50-ohm load. The LHO063 is not internally current limited, giving added versatility and higher transient drive capability.

LH0063 Pinout

LH0063 Features

  • Pin for Pin 2nd Source
  • 6000V/Sec Slew Rate
  • DC to 300MHz Bandwidth
  • 10V Output Drive Into 50
  • 2ns Rise and Fall Times
  • Wide Range Single or Dual Supply Operation
  • 10 Ohm Input Resistance

Application

  • High Speed Line Drivers
  • Video Drivers/Impedance Transformation
  • Nuclear Instrumentation Amplifiers
  • Operational Amplifier Isolation
  • High Speed A to D Input Buffers
  • Video Cross Point Switches

You can download this datasheet for LH0063 Ultra Fast Buffer – Datasheet from the link given below:
