KTC3209 NPN Power Switching Transistor is designed for power amplifier application.KTC3209 is Complementary to KTA1281.
KTC3209 Pinout
KTC3209 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Emitter |
| 2 | Collector |
| 3 | Base |
KTC3209 Key Features
- Low Saturation Voltage
- High Speed Switching Time
- Complementary to KTA1281
KTC3209 Specification
| Name | Description |
|---|---|
| Collector-Emitter Voltage (Vce) | 50 V |
| Collector-Base Voltage (Vcb) | 50 V |
| Emitter-Base Voltage (Veb) | 5 V |
| Collector Current (Ic) | 2 A |
| Collector Power Dissipation (Pc) | 1 W |
| Transition Frequency | 100 MHz |
Application
- Power Amplifier Application
- Power Switching Application
You can download this datasheet for KTC3209 NPN Power Switching Transistor – Datasheet from the link given below:
