J201 JFET N Channel Transistor is designed primarily for low level audio and general, purpose applications with high impedance signal sources.
J201 Pinout
J201 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Drain |
| 2 | Source |
| 3 | Gate |
J201 Key Features
- Type Designator: J201
- Type of Transistor: JFET
- Type of Control Channel: N -Channel
- Package: TO92
- Low Cutoff Voltage
- High Input Impedance
- Very Low Noise
- High Gai
J201 Specification
| Id(A) | P d(W) | V ds(V) | V gs(V) | T j(C) |
| 0.06 | 0.625 | 40 | 1.5 | 150 |
J201 Equivalent/Alternate
- J201, LJ2015-53, 2SJ201, LJ2015-52, MMBFJ201, CJ201NL
Applications
- High-Gain, Low-Noise Amplifiers
- Low-Current, Low-Voltage
- Battery-Powered Amplifiers
- Infrared Detector Amplifiers
- Ultra High Input
You can download this datasheet for J201 JFET N Channel Transistor from the link given below:
