IRF640 18A 200V N-Channel Power MOSFET – Datasheet

5,406 views

IRF640 18A 200V N-Channel power MOSFET is designed using the company’s consolidated strip layout-based MESH OVERLAY process. This technology matches and improves the performances compared with standard parts from various sources.

IRF640 Pinout

IRF640 Pin Configuration

Pin NoPin Name
1Gate
2Drain
3Source

IRF640 Key Features

  • Low on-state resistance VDSS = 200 V
  • Fast switching
  • Low thermal resistance
  • Extremely High dV/dt Capability
  • Type Designator: IRF640
  • Type of Transistor: MOSFET
  • Type of Control Channel: N -Channel

IRF640 Specification

Id (A)Pd (W)Vds (max)Rds (on)Vgs (max)
181252000.1820

IRF640 Equivalent/Alternative

  • IRF034, IRF044, IRF044SMD, IRF054, IRF054SMD, IRF100B201

Application

  • Switching Application
  • High Current Switching
  • Uninterruptible Power Supply (UPS)

You can download this datasheet for IRF640 18A 200V N-Channel Power MOSFET from the link given below:
