IRF540 30A 100V N-Channel Power MOSFET is designed to withstand high energy in the avalanche and commutation modes. This new energy efficient design also offers a drain–to–source diode with a fast recovery time. Designed for low voltage, high speed switching applications in power supplies, converters, and PWM motor controls.
IRF540 Pinout
IRF540 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Gate |
| 2 | Drain |
| 3 | Source |
IRF540 Key Features
- Avalanche Energy Specified
- Source–to–Drain Diode Recovery Time Comparable to a
- Discrete Fast Recovery Diode
- Diode is Characterized for Use in Bridge Circuits
- IDSS and VDS(on) Specified at Elevated Temper
- Type Designator: IRF540
- Type of Transistor: MOSFET
- Type of Control Channel: N -Channel
IRF540 Specification
| Id (A) | Pd (W) | Vds (max) | Rds (on) | Vgs (max) |
|---|---|---|---|---|
| 30 | 150 | 100 | 0.077 | 20 |
IRF540 Equivalent /Alternative
- IRF034, IRF044, IRF044SMD, IRF054, IRF054SMD, IRF100B201
Application
- D.C to D.C converters
- switched mode power supplies
- T.V. and computer monitor power supplies
You can download this datasheet for IRF540 30A 100V N-Channel Power MOSFET from the link given below:
