IRF1010 85A 55V N-Channel Power MOSFET – Datasheet

4,301 views

IRF1010 85A 55V N-Channel Power MOSFETs from International Rectifier utilize advanced processing techniques to achieve extremely low on-resistance per silicon area. This benefit, combined with the fast switching speed and ruggedized device design that HEXFET power MOSFETs are well known for, provides the designer with an extremely efficient and reliable device for use in a wide variety of applications. The TO-220 package is universally preferred for all commercial-industrial applications at power dissipation levels to approximately 50 watts.

IRF1010 Pinout

IRF10101 Pin Configuration

Pin NoPin Name
1Gate
2Drain
3Source

IRF1010 Key Features

  • Advanced Process Technology
  • Ultra Low On-Resistance
  • Dynamic dv/dt Rating
  • 175°C Operating Temperature
  • Fast Switching
  • Fully Avalanche Rated
  • Type Designator: IRF1010
  • Type of Transistor: MOSFET
  • Type of Control Channel: N -Channel

IRF1010 Specification

Id (A)Pd (W)Vds (max)Rds (on)Vgs (max)
72130550.01210

IRF1010 Equivalent/Alternative

  • IRF034, IRF044, IRF044SMD, IRF054, IRF054SMD, IRF100B201

Application

  • Power Supply
  • Switching Applications

You can download this datasheet for IRF1010 85A 55V N-Channel Power MOSFET from the link given below:
