FR604 400V 6A Fast Recovery Diode – Datasheet

2,222 views

FR604 400V 6A Fast Recovery Diode is Fast switching, Low leakage, Low forward voltage drop, and High current capability.

FR604 Features & Specification

  • Peak Repeat. Reverse Voltage (Vrrm): 400V
  • Max. RMS Reverse Voltage (Vr): 280V
  • Average Rectified Current (Io): 6.0A
  • Max. Reverse Current (Ir): 0.010mA
  • Max. Forward Voltage Drop (Vf): 1.3V
  • Reverse Recovery Time (Trr): 150ns

You can download this datasheet for FR604 400V 6A Fast Recovery Diode from the link given below:
