The DAC0806LCN series is an 8-bit monolithic digital-to-analog converter (DAC) featuring a full scale output current settling time of 150 ns while dissipating only 33 mw with g5V supplies. No reference current (IREF) trimming is required for most applications since the full scale output current is typically g1 LSB of 255 IREF/ 256. Relative accuracies of better than g0.19% assure 8-bit monotonicity and linearity while zero level output current of less than 4 mA provides 8-bit zero accuracy for IREFt2 mA. The power supply currents of the DAC0808 series are independent of bit codes, and exhibits essentially constant device characteristics over the entire supply voltage range.
DAC0806LCN Pinout
DAC0806LCN Pin Configuration
| Pin Number | Pin Name | Description |
|---|---|---|
| 1 | NC | Not Connected |
| 2 | GND | Ground |
| 3 | Vee | Negative Supply |
| 4 | Iout | Current Out |
| 5 | A1 | Digital Input Bit 1 |
| 6 | A2 | Digital Input Bit 2 |
| 7 | A3 | Digital Input Bit 3 |
| 8 | A4 | Digital Input Bit 4 |
| 9 | A5 | Digital Input Bit 5 |
| 10 | A6 | Digital Input Bit 6 |
| 11 | A7 | Digital Input Bit 7 |
| 12 | A8 | Digital Input Bit 8 |
| 13 | V+ | Positive Supply |
| 14 | Vref+ | Positive Voltage Reference |
| 15 | Vref- | Negative Voltage Reference |
| 16 | COMP | Compensation |
DAC0806LCN Features
- Relative accuracy: g0.19% error maximum (DAC0808)
- Full scale current match: g1 LSB typ
- 7 and 6-bit accuracy available (DAC0807, DAC0806)
- Fast settling time: 150 ns typ
- Noninverting digital inputs are TTL and CMOS compatible
- High speed multiplying input slew rate: 8 mA/ms
- Power supply voltage range: g4.5V to g18V
- Low power consumption: 33 mw
Application
- 10V Output Digital to Analog Converter
You can download this datasheet for DAC0806LCN 8-bit D/A Converter from the link given below:
