C122M 8A 600V SCR – Datasheet

2,052 views

C122M 8A 600V medium power silicon controlled rectifier is designed for full-wave ac control applications, such as motor controls, heating controls, and power supplies or wherever half-wave silicon gate-controlled, solid-state devices are needed.

C122M Pinout

C122M Pin Configuration

Pin NoPin Name
1Cathode
2Anode
3Gate

C122M Key Features

  • Electrically Isolated Packages
  • High Voltage Capability: 30-600V
  • High Surge Capability: Up to 950 Amp
  • Glass Passivated Chip

C122M Specification

TypeVdsm (V)dV/dT (V/µs)Vgt (V)It (A)Igt (uA)
C122M600 501.58.025.0

Application

  • It is used for a wide range of switching applications
  • It is used for a wide range of switching applications
  • Motor controls
  • Heating controls
  • Power supplies

You can download this datasheet for C122M 8A 600V SCR – Datasheet from the link given below:
