N-channel enhancement mode vertical D-MOS transistor in TO-92 variant envelope and intended for use in relay, high-speed and line-transformer drivers.
BS170 Pinout
BS170 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Drain |
| 2 | Gate |
| 3 | Source |
BS170 Key Features
- Very low RDS(on)
- Direct interface to C-MOS, TTL, etc.
- High-speed switching
- No secondary breakdown
Specification
| Id (mA) | Pd | Vds (max) | Vgs | Rds | cd(pF) |
|---|---|---|---|---|---|
| 0.5 | 0.83 | 60 | 20 | 5 | 0 |
BS170 Equivalent/Alternate:
- BS107A, BS107P, BS107PT, BS108, BS170F, BS170P
Application
- Small Servo Motor Control
- Power MOSFET Gate Driver
- Switching Applications
You can download this datasheet for BS170 0.5A 60V N-Channel Switching FET from the link given below:
