BF872 PNP High Voltage Transistor is designed for use in class-B video output stages of colour television receivers. PNP transistors in a TO-202 plastic package.
BF872 Pinout
BF872 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Emitter |
| 2 | Collector |
| 3 | Base |
BF872 Key Features
- Low feedback capacitance.
Specification
| Maximum Collector Power Dissipation (Pc) | 1.6 W |
| Maximum Collector-Base Voltage |Vcb| | 300 V |
| Maximum Collector-Emitter Voltage |Vce| | 300 V |
| Maximum Emitter-Base Voltage |Veb| | 5 V |
| Maximum Collector Current |Ic max| | 0.03 A |
| Type Designator | BF872 |
Application
- For use in class-B video output stages of colour television receivers.
You can download this datasheet for BF872 PNP High Voltage Transistor – Datasheet from the link given below:
