BF422 NPN High Voltage Transistor is designed for Class-B video output stages in colour television and professional monitor equipment. NPN transistors in a TO-92 plastic package.
BF422 Pinout
BF422 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Emitter |
| 2 | Collector |
| 3 | Base |
BF422 Key Features
- Low feedback capacitance.
Specification
| Maximum Collector Power Dissipation (Pc) | 0.83 W |
| Maximum Collector-Base Voltage |Vcb| | 250 V |
| Maximum Collector-Emitter Voltage |Vce| | 250 V |
| Maximum Emitter-Base Voltage |Veb| | 5 V |
| Maximum Collector Current |Ic max| | 0.2 A |
| Type Designator | BF422 |
Application
- Class-B video output stages in colour television and professional monitor equipment
You can download this datasheet for BF422 NPN High Voltage Transistor – Datasheet from the link given below:
