The BF258 is silicon planar epitaxial NPN transistors in the Jedec TO-39 metal case. BF258 is particularly designed for video output stages in CTV and MTV sets, class A audio output stages, and drivers for horizontal deflection circuits
BF258 Pinout
BF258 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Emitter |
| 2 | Base |
| 3 | Collector |
Specification
| Type Designator | BF258 |
| Maximum Collector Power Dissipation (Pc) | 0.8 W |
| Maximum Collector-Base Voltage |Vcb| | 250 V |
| Maximum Collector-Emitter Voltage |Vce| | 250 V |
| Maximum Collector Current |Ic max|: | 0.1 A |
Application
- Designed for video output stages in CTV and MTV
You can download this datasheet for BF258 NPN High Voltage Transistor – Datasheet from the link given below:
