BF245 N-Channel Amplifier is designed for LF, HF, and DC amplifiers. General-purpose N-channel symmetrical junction field-effect transistors in a plastic TO-92 variant package
BF245 Pinout
BF245 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Drain |
| 2 | Source |
| 3 | Gate |
BF245 Key Features
- Interchangeability of drain and source connections
- Frequencies up to 700 MHz
Specification
| Type Designator | BF245 |
| Maximum Collector Power Dissipation (Pc) | 0.35 W |
| Maximum drain-source Voltage |Vds| | 40 V |
| Maximum Collector Current |Id max|: | 0.065 A |
Application
- LF, HF and DC amplifiers.
You can download this datasheet for BF245 N-Channel Amplifier – Datasheet from the link given below:
