BDT65 NPN Power Transistor is used for audio output stages and general purpose amplifier and switching applications
Power Transistor?
Transistors are three-terminal semiconductor electronic devices that can be used as switches or amplifiers. They can be of NPN or PNP polarity, and many different types are available with different power and switching speed ratings. If a transistor designed to these concepts can handle more than 1 A of collector current, it is generally considered to be a power transistor. Such transistors must have low output resistance to deliver large load currents, and good junction insulation to resist high voltages. They must also dissipate heat very quickly to avoid overheating.
BDT65 Pinout
BDT65 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Base |
| 2 | Collector |
| 3 | Emitter |
BDT65 Key Features
- Collector Current -IC= 12A
- High DC Current Gain-hFE= 1000(Min)@ IC= 5A
- Minimum Lot-to-Lot variations for robust device performance and reliable operation
- Type Designator: BDT65A
- Material of Transistor: Si
- Polarity: NPN
- Package: TO220
BDT65 Specification
| Ic (mA) | Pd | Vce (max) | Vcb | hfe | Ft |
|---|---|---|---|---|---|
| 12 | 125 | 80 | 80 | 2000 | 20 |
BDT65 Equivalent/Alternate:
- BDT29, BDT64, BDT30
Application
- Audio Output Stages
- General Purpose Amplifier
You can download this datasheet for BDT65 NPN Power Transistor from the link given below:
