BD433 NPN Medium Power Transistor – Datasheet

2,750 views

The BD433 is silicon epitaxial-base NPN power transistors in Jedec SOT-32 plastic package, intended for use in medium power linear and switching applications. The BD433 is especially suitable for use in car-radio output stages

Power Transistor?

Transistors are three-terminal semiconductor electronic devices that can be used as switches or amplifiers. They can be of NPN or PNP polarity, and many different types are available with different power and switching speed ratings. If a transistor designed to these concepts can handle more than 1 A of collector current, it is generally considered to be a power transistor. Such transistors must have low output resistance to deliver large load currents, and good junction insulation to resist high voltages. They must also dissipate heat very quickly to avoid overheating.

BD433 Pinout

BD433 Pin Configuration

Pin NoPin Name
1Emitter
2Collector
3Base

BD433 Key Features

  • Collector-Emitter Sustaining Voltage –
    • : VCEO(SUS)= 22V(Min)
  • Minimum Lot-to-Lot variations for robust device performance and reliable operation
  • Type Designator: BD433
  • Material of Transistor: Si
  • Polarity: NPN
  • Maximum Emitter-Base Voltage |Veb|: 5 V

BD433 Specification

Ic (mA)PdVce (max)Vcb hfe@IcFT
436222240-130103

BD433 Equivalent/Alternate:

  • BD410, BD414, BD433-10, BD434, BD434

Application

  • Medium Power Linear
  • Switching Applications
  • General Purpose Amplifier

You can download this datasheet for BD433 NPN Medium Power Transistor from the link given below:
