The BD244 PNP Power Transistor is manufactured in Planar technology with “Base Island” layout. The resulting transistor shows exceptional high gain performance coupled with very low saturation voltage. The PNP type is BD244C.
Power Transistor?
Transistors are three-terminal semiconductor electronic devices that can be used as switches or amplifiers. They can be of NPN or PNP polarity, and many different types are available with different power and switching speed ratings. If a transistor designed to these concepts can handle more than 1 A of collector current, it is generally considered to be a power transistor. Such transistors must have low output resistance to deliver large load currents, and good junction insulation to resist high voltages. They must also dissipate heat very quickly to avoid overheating.
BD244 Pinout
BD244 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Base |
| 2 | Collector |
| 3 | Emitter |
BD244 Key Features
- DC Current Gain -hFE =30(Min)@ IC= -0.3A
- Collector-Emitter Sustaining Voltage-
- : VCEO(SUS) = -100V(Min)- BD243C
- Minimum Lot-to-Lot variations for robust device performance and reliable operation
- Type Designator: BD244
- Material of Transistor: Si
- Polarity: PNP
- Maximum Emitter-Base Voltage |Veb|: 5 V
BD244 Specification
| Ic (mA) | Vce (max) | Vcb | hfe | @Ic | FT |
|---|---|---|---|---|---|
| 6 | 45 | 45 | 30 | 300 | 3 |
BD244 Equivalent/Alternate:
- BD201, BD202, BD203, BD204, BD243
Application
- General Purpose Power Amplifier
- Power Linear And Switching
You can download this datasheet for BD244 PNP Power Transistor from the link given below:
