BD235 NPN Power Transistor – Datasheet

3,195 views

The BD235 is silicon epitaxial-base NPN power transistors in Jedec SOT-32 plastic package intended for use in medium power linear and switching applications

Power Transistor?

Transistors are three-terminal semiconductor electronic devices that can be used as switches or amplifiers. They can be of NPN or PNP polarity, and many different types are available with different power and switching speed ratings. If a transistor designed to these concepts can handle more than 1 A of collector current, it is generally considered to be a power transistor. Such transistors must have low output resistance to deliver large load currents, and good junction insulation to resist high voltages. They must also dissipate heat very quickly to avoid overheating.

BD235 Pinout

BD235 Pin Configuration

Pin NoPin Name
1Emitter
2Collector
3Base

BD235 Key Features

  • Low saturation voltage
  • DC Current Gain-
    • : hFE= 40(Min)@ IC= 0.15A
  • Minimum Lot-to-Lot variations for robust device performance and reliable operation
  • Type Designator: BD235
  • Material of Transistor: Si
  • Polarity: NPN

BD235 Specification

Ic (mA)Vce (max)Vcb hfe@IcFT
26060401503

BD235 Equivalent/Alternate:

  • BD201, BD202, BD203, BD204, BD236

Application

  • Audio
  • Power Linear And Switching
  • General Purpose

You can download this datasheet for BD235 NPN Power Transistor from the link given below:
