BC550 NPN General Purpose Transistor is designed for low noise stages in audio frequency equipment.NPN transistor in a TO-92; SOT54 plastic package.
BC550 Pinout
BC550 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Collector |
| 2 | Base |
| 3 | Emitter |
BC550 Key Features
- Low current (max. 100 mA)
- Low voltage (max. 45 V)
Specification
| Type Designator | BC550 |
| Maximum Collector Power Dissipation (Pc) | 0.5 W |
| Maximum Collector-Base Voltage |Vcb| | 50 V |
| Maximum Collector-Emitter Voltage |Vce| | 45 V |
| Maximum Emitter-Base Voltage |Veb| | 6 V |
| Maximum Collector Current |Ic max|: | 0.1 A |
Application
- Low noise stages in audio frequency equipment
You can download this datasheet for BC550 NPN Low Noise Transistor – Datasheet from the link given below:
