BC549 NPN General Purpose Transistor – Datasheet

5,926 views

BC549 NPN General Purpose Transistor is designed for low noise stages in audio frequency equipment.NPN transistor in a TO-92; SOT54 plastic package.

BC549 Pinout

BC549 Pin Configuration

Pin NoPin Name
1Collector
2Base
3Emitter

BC549 Key Features

  • Low current (max. 100 mA)
  • Low voltage (max. 45 V)

BC549 Specification

Type DesignatorBC549
Maximum Collector Power Dissipation (Pc)0.5 W
Maximum Collector-Base Voltage |Vcb|30 V
Maximum Collector-Emitter Voltage |Vce|30 V
Maximum Emitter-Base Voltage |Veb|6 V
Maximum Collector Current |Ic max|: 0.1 A

Application

  • Low noise stages in audio frequency equipment

You can download this datasheet for BC549 NPN General Purpose Transistor – Datasheet from the link given below:
