BC546 NPN Transistor – Datasheet

BC546 is an NPN epitaxial silicon transistor that is available in a TO-92 package. This transistor is very popular for its high voltage characteristics where the maximum voltage across collector-emitter (VCE) could be 65V and a maximum collector current of 100mA. It’s a low power loss, high-efficiency transistor ideal for automated placement with high surge current capability.

BC546 Transistor Pinout

PIN NUMBER	PIN NAME
1	Collector
2	Base
3	Emitter

Features and specifications:

• Type: NPN epitaxial silicon transistor
• DC Current Gain (h_FE): 110- 800
• Collector current (I_C): 100mA
• Collector Base Voltage (VCB): 80 V
• Collector-Emitter voltage (VCE): 65V
• Emitter Base Voltage (VEB): 6V
• Maximum Power dissipation: 500mW
• Junction temperature: 150⁰C
• Current gain-bandwidth product: 300MHz
• Noise figure: 10 dB
• Available in TO-92 Package

Applications and uses:

• High voltage, low noise amplifier designs
• Switching small loads
• Small signal amplifiers
• Darlington pair
• Pre-amplifier circuits
• Audio Noise filters
