An Overview
The module comprises an accurate, low-offset straight Hall circuit with a copper conduction path. Applied current flows through this copper conduction path which produces the magnetic field which the Hall IC converts into a corresponding voltage. We can adjust module precision or accuracy through the nearness of the magnetic signal to the Hall transducer. The low-offset Hall IC, which is programmed for precision at the industrial facility provides A precise, proportional output voltage.
Features and Specifications of ACS758
Features
- Industry-leading noise performance through proprietary amplifier and filter design techniques
- Integrated shield reduces capacitive coupling from current conductor to die because of high dV/dt signals, and prevents offset drift in high-side, high-voltage applications
- Total output error improvement through gain and offset trim over temperature
- Small package size, with easy mounting capability
- Monolithic Hall IC for high reliability
- Ultra-low power loss: 100 μΩ internal conductor resistance
- Galvanic isolation allows use in economical, high-side current sensing in high-voltage systems
- AEC Q-100 qualified
Specifications
- Brand Name: ARTOU
- Usage: Hall
- Current Sensoris_customized: Yes
- Type: Optical-Electronics Sensor
- Theory: Hall Sensor
- Output: Analog Sensor
- Model Number: ACS758LCB Hall Current Sensor
- Material: Mixture
- 3.0 to 5.5 V, single supply operation
- 120 kHz typical bandwidth
- 3 μs output rise time in response to step input current
- Output voltage proportional to AC or DC currents
- Factory-trimmed for accuracy
- Extremely stable output offset voltage
- Nearly zero magnetic hysteresis
Pinouts of ACS758
| Pin Number | Pin Name | Description |
| 1. | Vcc | Power supply pin |
| 2. | GND | Ground terminal |
| 3. | VIOUT | Analog output |
| 4. | IP+ | Terminal for current being sampled |
| 5. | IP- | Terminal for current being sampled |
Applications of ACS758 Module
Water Stations
We can use the module in water stations since it has a stable structure, excellent performance, and long service life, therefore ideal for water landscapes.
Other Applications
- Measuring equipment.
- Machines that require precise measurements.
