The ULN2804 Octal Peripheral Driver NPN Darlington connected transistors in this family of arrays are ideally suited for interfacing between low logic level digital circuitry (such as TTL, CMOS, or PMOS/NMOS) and the higher current/voltage requirements of lamps, relays, printer hammers or other similar loads for a broad range of computer, industrial, and consumer applications. All devices feature open-collector outputs and freewheeling clamp diodes for transient suppression. le the ULN2804 is optimized for 6 to 15 volt high-level CMOS or PMOS.
ULN2804 Pinout
ULN2804 Pin Configuration
| Pin No | Pin Name | Description |
|---|---|---|
| 1 | 1B | Input Pin1B |
| 2 | 2B | Input Pin 2B |
| 3 | 3B | Input Pin 3B |
| 4 | 4B | Input Pin 4B |
| 5 | 5B | Input Pin 5B |
| 6 | 6B | Input Pin 6B |
| 7 | 7B | Input Pin 7B |
| 8 | 8B | Input Pin 8B |
| 9 | GND | Ground Pin |
| 10 | COM | Common Pin |
| 11 | 8C | Output Pin 8C |
| 12 | 7C | Output Pin 7C |
| 13 | 6C | Output Pin 6C |
| 14 | 5C | Output Pin 5C |
| 15 | 4C | Output Pin 4C |
| 16 | 3C | Output Pin 3C |
| 17 | 2C | Output Pin 2C |
| 18 | 1C | Output Pin 1C |
ULN2804 Features
- Open–collector outputs
- Free wheeling clamp diodes
Application
- Industrial application
- Consumer applications
- Lamps
- Relays
- Printer
- Hammers
- Broad range of computer
You can download this datasheet for ULN2804 Octal Peripheral Driver Arrays – Datasheet from the link given below:
