The 93LC66 is 4K, low-voltage serial Electrically Erasable PROMs. The device memory is configured as x8 or x16 bits, depending on the ORG pin setup. Advanced CMOS technology makes these devices ideal for low-power, nonvolatile memory applications. The 93LC66 is available in standard 8-pin DIP and 8/ 14-pin surface mount SOIC packages. The 93LC66 is only offered in an “SN” package.
93LC66 Pinout
93LC66 Pin Configuration
Pin No | Pin Name | Description |
---|---|---|
1 | CS | Chip Select Pin |
2 | CLK | Clock Pin |
3 | DI | Digital Input Pin |
4 | D0 | Digital Output Pin |
5 | VSS | Ground Pin |
6 | ORG | Memory Configuration Pin |
7 | NU | Not Utilize Pin |
8 | VCC | Power Supply Pin |
93LC66 Key Feature
- Single supply with programming operation down
- to 2.0V (Commercial only)
- Low power CMOS technology
- 1 mA active current typical
- 5 µA standby current (typical) at 3.0V
- ORG pin selectable memory configuration
- 128 x 8 or 64 x 16-bit organization (93LC46)
- 256 x 8 or 128 x 16-bit organization(93LC56)
- 512 x 8 or 256 x 16-bit organization(93LC66)
- Self-timed ERASE and WRITE cycles (including auto-erase)
- Automatic ERAL before WRAL
- Power on/off data protection circuitry
- Industry standard 3-wire serial I/O
- Device status signal during ERASE/WRITE cycle
You can download this datasheet for 93LC66 4K EEPROM – Datasheet from the link given below:
