8288A Bus Controller is a 20-pin bipolar component for use with medium-ta-large SAB 80186, SAB 80188, SAB 8086, and SAB 8088 processing systems. The bus controller provides command and control timing generation as well as bipolar bus drive capability while optimizing system performance. A strapping option on the bus controller configures it for use with a multi-master system bus and separate /0 bus.
8288 Pinout
8288 Pin Configuration
| Pin Number | Pin Name | Description |
|---|---|---|
| 1 | IO B | Input/Output Bus Mode |
| 2 | CLK | Clock |
| 3 | S1 | Status Pin |
| 4 | DT/R | Data Transmit/Receive |
| 5 | ALE | Address Latch Enable |
| 6 | AEN | Address Enable |
| 7 | MRDC | Memory Read |
| 8 | AMWC | Advanced Memory Write |
| 9 | MWTC | Memory Write |
| 10 | GND | Ground |
| 11 | IOW C | I/O Write |
| 12 | AIOWC | Advanced 1/O Write Pin |
| 13 | IROC | 1/O Read |
| 14 | INTA | Interrupt Acknowledge |
| 15 | CEN | Command Enable |
| 16 | DEN | Data Enable Pin |
| 17 | MCE/PDA | Master Cascade/Peripheral Data |
| 18 | S2 | Status Pin |
| 19 | S0 | Status Pin |
| 20 | VCC | Supply Voltage |
8288 Key Features
- Fully compatible with SAB 8288 40% Less Power Supply Current than Standard SAB 8288
- Bipolar Drive Capability
- Provides Advanced Commands
- 3-State Command Output Drivers
- Configurable for Use with an 1/O Bus
- Facilitates Interface to One or Two Multi-Master Busses
You can download this datasheet for 8288 Bus Controller – Datasheet from the link given below:
