79L12 -12V Negative Regulator (100mA) – Datasheet

The LM79L12 is a 3-terminal negative voltage regulator that features fixed output voltages of −12V with output current capabilities in excess of 100mA. This device was designed using the latest computer techniques for optimizing the packaged IC thermal or electrical performance.

The LM79L12 also includes, as self-protection circuitry: safe operating area circuitry for output transistor power dissipation limiting, a temperature-independent short circuit current limit for peak output current limiting, and a thermal shutdown circuit to prevent excessive junction temperature. Although designed primarily as fixed voltage regulators.

79L12 Pinout

79L12 Pin Configuration

Pin No	Pin Name
1	Ground
2	Input
3	Output

79L12 Key Features

• Preset output voltage error is less than ±5% overload, line and temperature
• Specified at an output current of 100mA
• Easily compensated with a small 0.1µF output capacitor
• Internal short-circuit, thermal and safe operating area protection
• Easily adjustable to higher output voltages
• Maximum line regulation less than 0.07% VOUT/V
• Maximum load regulation less than 0.01% VOUT/mA
• See AN-1112 for micro SMD considerations

Application

• Power dissipation limiting
• Temperature independent
• Short circuit current limit
