The LM79L05 is a 3-terminal negative voltage regulator that features fixed output voltages of −5V with output current capabilities in excess of 100mA. This device was designed using the latest computer techniques for optimizing the packaged IC thermal or electrical performance.
The LM79L05 also includes, as self-protection circuitry: safe operating area circuitry for output transistor power dissipation limiting, a temperature-independent short circuit current limit for peak output current limiting, and a thermal shutdown circuit to prevent excessive junction temperature.
79L05 Pinout
79L05 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Ground |
| 2 | Input |
| 3 | Output |
79L05 Key Features
- Preset output voltage error is less than ±5% overload, line and temperature
- Specified at an output current of 100mA
- Easily compensated with a small 0.1µF output capacitor
- Internal short-circuit, thermal and safe operating area protection
- Easily adjustable to higher output voltages
- Maximum line regulation less than 0.07% VOUT/V
- Maximum load regulation less than 0.01% VOUT/mA
- See AN-1112 for micro SMD considerations
Application
- voltage regulators
You can download this datasheet for 79L05 -5V Negative Regulator (100mA) – Datasheet from the link given below:
