LM78L09 +9V Positive Regulator (100mA) – Datasheet

The LM78L09 is the three-terminal positive regulator available with several fixed output voltages making them useful in a wide range of applications. When used as a Zener diode/resistor combination replacement, the LM78L09 results in effective output impedance improvement of two orders of magnitude, and lower quiescent current.

This regulator can provide local on-card regulation, eliminating the distribution problems associated with single-point regulation. The voltages available allow the LM78L09 to be used in logic systems, instrumentation, HiFi, and other solid-state electronic equipment.

78L09 Pinout

78L09 Pin Configuration

Pin No	Pin Name
1	Output
2	Ground
3	Input

78L09 Key Features

• LM78L05 in micro SMD package
• Output voltage tolerances of ±5% over the temperature range
• The output current of 100 mA
• Internal thermal overload protection
• Output transistor safe area protection
• Internal short circuit current limit
• Available in plastic TO-92 and plastic SO-8 low profile packages
• No external components
• Output voltages of 5.0V, 6.2V, 8.2V, 9.0V, 12V, 15V

Application

• fixed output voltages

You can download this datasheet for 78L09 +9V Positive Regulator (100mA) – Datasheet from the link given below:
