74LS175 IC is a member of the 74XXYY IC series. The 74LS175 is a low Schottky high speed Quad D Flip-Flop. The device is useful for general flip-flop requirements where the clock and clear inputs are common. The information on the D inputs is stored during the LOW to HIGH clock transition. Both true and complemented outputs of each flip-flop are provided. A Master Reset input resets all flip-flops, independent of the Clock or D inputs, when LOW. The 74LS175 IC has a wide range of working conditions, and directly interfaces with CMOS, NMOS, and TTL. The output of the IC always comes in TTL which makes it easy to work with other TTL devices and microcontrollers.
What is a D-Type Flip-Flop?
A D-type flip-flop is a clocked flip-flop which has two stable states. A D-type flip-flop operates with a delay in input by one clock cycle. Thus, by cascading many D-type flip-flops delay circuits can be created, which are used in many applications such as in digital television systems. A D-type flip-flop is also known as a D flip-flop or a delay flip-flop.
74LS175 Pinout
74LS175 Pin Configuration
| Pin No | Pin Name | Description |
|---|---|---|
| 1 | MR’ | Active low Master Reset Input |
| 2 | Q0 | True Output 0 |
| 3 | Q0‘ | Complemented Output 0 |
| 4 | D0 | Data input 0 |
| 5 | D1 | Data input 1 |
| 6 | Q1‘ | Complemented Output 1 |
| 7 | Q1 | True Output 1 |
| 8 | GND | Ground Pin |
| 9 | CP | Clock Input |
| 10 | Q2 | True Output 2 |
| 11 | Q2‘ | Complemented Output 2 |
| 12 | D2 | Data input 2 |
| 13 | D3 | Data input 3 |
| 14 | Q3‘ | Complemented Output 3 |
| 15 | Q3 | True Output 3 |
| 16 | VCC | Chip Supply Voltage |
74LS175 Features & Specifications
- Channels (#): 4
- Technology Family: LS
- VCC (Min): 4.75V
- VCC (Max): 5.25V
- Input type: Bipolar
- Output type: Push – Pull
- Clock Frequency (Max): 35MHz
- Edge-Triggered D-Type Inputs
- Buffered-Positive Edge-Triggered Clock
- Clock to Output Delays of 30 ns
- Asynchronous Common Reset
- True and Complement Output
- Input Clamp Diodes Limit High Speed Termination Effects
- IOL (Max): 8mA
- IOH (Max): -0.4mA
- ICC (Max): 18000uA
- Propagation speed(tpd): 10 – 50ns
Applications
- It is commonly used in devices such as PCs, notebooks, Digital Electronic & Network equipment, etc.
- It is also used in memory registers of many computing devices such as laptops & personal computers.
You can download this Datasheet for 74LS175 Quadruple D-Type Flip-Flop from the link given below:
